PD Caps - Adhesive Lined Heat Shrink End Cap | Raychem/TE Connectivity

Heat-shrinkable, dual wall PD Caps inexpensively encapsulate crimped electrical connections, including those on motor coils. They remain tightly in place for the life of the motor. PD Caps are manufactured from radiation-crosslinked polyolefin.

With brief heating, the outer jacket wall flows into voids in the crimp, creating an encapsulated and electrically insulated connection.

Our adhesive Lined Heat Shrinkable PD Caps from TE connectivity remain tightly in place under the most strenuous conditions, manufactured from radiation-crosslinked polyolefin.

Please click the variations below to add to your product selection

0 Items in your selection £0.00 Selection Total
Back

  • Text
  • Number
  • Text & Number

Text Element

Text & Number Element

Number Element

Skip Personalisation | Request a Callback

Various Pack Sizes

See below for more options

As low as £0.99 £1.19
In stock
Only %1 left
SKU
PD-CAP

These end caps are a smaller option below and out-side our standard HENc range of heat shrink end caps.

Heat-shrinkable, dual wall PD Caps inexpensively encapsulate crimped electrical connections, including those on motor coils. They remain tightly in place for the life of the motor. PD Caps are manufactured from a radiation-crosslinked polyolefin.

With brief heating, the outer jacket wall flows into voids in the crimp, creating an encapsulated and electrically insulated connection. PD Caps are not intended for use where immersion in fluids is required.

An operator can insulate connections at approximately twice the speed of conventional methods, which require tape-wrapping, or slip-on tubing. PD Caps can be installed in seconds using standard hot-air or infrared heating tools. No special operator training is required.

  • Fully recovered temperature: 135°C

  • Continuous operating temperature: -55°C to 110°C

  • Seals & protects cable ends from the environmental effects
